Product Description FAQ

Product Description

S235JO is a grade of structural steel, and an angle steel bar made of this grade is commonly used in construction and engineering projects. The chemical composition and mechanical properties of S235JO angle steel bar are as follows:

Chemical composition:

Carbon (C): 0.17%
Silicon (Si): 0.35%
Manganese (Mn): 1.40%
Phosphorus (P): 0.045%
Sulfur (S): 0.045%

Mechanical properties:

Yield strength (σy): 225 MPa
Tensile strength (σb): 360-510 MPa
Elongation (δ): 21%
Impact energy (KV): 27 Joules at 0°C

Product Details

Product Name	Angle steel Bar
Standard	S235JR/S235J0/S355J0/S355J2/A283/A516/A572/A36/SS400
Shape	Equal and Unequal
thickness	3-30mm
width	20-200mm
length	6m,9m,12m
Surface treatment	Black/Galvanized
Technique	Hot Rolled
Application	Construction,Structure
MOQ	5TON
package	Standard Seaworthy Package
Delivery time	within 15days
payment term	TT30%/LC
Origin	CHINA

*EQUAL ANGLE (AT)**
Size(mm)	Theoratical Weight (kg/m)	Size(mm)	Theoratical Weight (kg/m)	Size(mm)	Theoratical Weight (kg/m)
25*3	1. 134	75*7	7.976	110*14	22.809
25*4	1. 459	75*8	9.03	125*8	15.504
30*3	1. 373	75*10	11. 089	125*10	19. 133
30*4	1. 786	80*6	7.376	125*12	22.696
40*3	1. 852	80*7	8.525	125*14	26. 193
40*4	2.422	80*8	9.658	140*10	21. 488
40*5	2.976	80*10	11. 874	140*12	25.522
50*4	3.059	90*6	8.35	140*14	29.49
50*5	3.77	90*7	9.658	140*16	35.393
50*6	4.465	90*8	10.946	160*10	24.729
60*5	4.52	90*10	13.476	160*12	29.391
60*6	5.42	90*12	15.94	160*14	33.987
63*5	4.822	100*6	9.366	160*16	38.518
63*6	5.721	100*7	10.83	180*12	33. 159
63*8	7.496	100*8	12.276	180*14	38.518
63*10	9. 151	100*10	15. 12	180*16	43.542
70*5	5.397	100*12	20.611	180*18	48.634
70*6	6.406	100*16	23.257	200*14	42.894
70*7	7.398	110*7	11. 928	200*16	48.68
70*8	8.373	110*8	13.532	200*18	54.401
75*5	5.818	110*10	16.69	200*20	60.056
75*6	6.905	110*12	19.782
