A516 Angle Steel Bar

A516 angle steel bar is a type of carbon steel angle bar that is primarily used in the fabrication of pressure vessels and boilers. It is produced in accordance with the ASTM A516 standard, which specifies that the material must be normalized and have a minimum tensile strength of 70 ksi (485 MPa) and a yield strength of 38 ksi (260 MPa). A516 angle steel bar is typically available in thicknesses ranging from 1/8 inch to 1 inch and in widths from 1 inch to 8 inches. The chemical composition of A516 angle steel bar typically includes carbon, manganese, phosphorus, sulfur, silicon, and copper.

Product Description

Product Name	Angle steel Bar
Standard	S275JR/S275J0/S355J0/S355J2/A283/A516/A572/A36/SS400
Shape	Equal and Unequal
thickness	3-30mm
width	20-200mm
length	6m,9m,12m
Surface treatment	Black/Galvanized
Technique	Hot Rolled
Application	Construction,Structure
MOQ	5TON
package	Standard Seaworthy Package
Delivery time	within 15days
payment term	TT30%/LC
Origin	CHINA



EQUAL ANGLE (A*T)
Size(mm)	Theoratical Weight (kg/m)	Size(mm)	Theoratical Weight (kg/m)	Size(mm)	Theoratical Weight (kg/m)
25*3	1. 134	75*7	7.976	110*14	22.809
25*4	1. 459	75*8	9.03	125*8	15.504
30*3	1. 373	75*10	11. 089	125*10	19. 133
30*4	1. 786	80*6	7.376	125*12	22.696
40*3	1. 852	80*7	8.525	125*14	26. 193
40*4	2.422	80*8	9.658	140*10	21. 488
40*5	2.976	80*10	11. 874	140*12	25.522
50*4	3.059	90*6	8.35	140*14	29.49
50*5	3.77	90*7	9.658	140*16	35.393
50*6	4.465	90*8	10.946	160*10	24.729
60*5	4.52	90*10	13.476	160*12	29.391
60*6	5.42	90*12	15.94	160*14	33.987
63*5	4.822	100*6	9.366	160*16	38.518
63*6	5.721	100*7	10.83	180*12	33. 159
63*8	7.496	100*8	12.276	180*14	38.518
63*10	9. 151	100*10	15. 12	180*16	43.542
70*5	5.397	100*12	20.611	180*18	48.634
70*6	6.406	100*16	23.257	200*14	42.894
70*7	7.398	110*7	11. 928	200*16	48.68
70*8	8.373	110*8	13.532	200*18	54.401
75*5	5.818	110*10	16.69	200*20	60.056
75*6	6.905	110*12	19.782
