WStE500 steel plate

According to EN 10025-2, S275J2 steel plate is mainly used in the construction industry and mechanical engineering, containers, tanks and rolled steel profiles such as angle steel, steel structure, H-beam, T-section. For S275J2 carbon steel, if customers want to improve the performance of the steel when using, our engineers still recommend normalizing heat treatment. Otherwise, the steel must undergo a low-temperature impact test at -20°C.

DIN WStE500 steel plate, as for the chemical composition, the different content is mainly in the carbon content, while the carbon content is A283Gr. d is not more than 0.27%, and higher than grade C (≤0.24%); As for the mechanical properties, the difference is in tensile strength and yield strength, while ASTM A283 Gr.D has a tensile strength of 415-550MPa (60-80 ksi) and ASTM A283 D grade has a yield strength of 230MPa (33 ksi).


Grade	C ≤	Si	Mn	P ≤	S ≤	N ≤	Al ≥	Cr ≤	Cu ≤	Mo ≤	Ni ≤	Nb ≤	Ti ≤	V ≤	Nb+Ti+V ≤
WStE500	0.21	0.10~0.60	1.00~1.70	0.035	0.030	0.020	0.020	0.30	0.20	0.10	1.00	0.05	---	0.22	0.22

Grades

Tensile Strength Rm for product thicknesses s,in mm N/mm²

UpperYield StressReH²) for product thicknesses s,in mm N/mm² min.

Elongation after fracture3) (Lo=5do) % min.

Mandrel diameter for bend test 4), 5)

s≤70

70＜s≤85

85＜s≤100

100＜s≤125

125＜s≤150

s≤16

16＜s≤35

35＜s≤50

50＜s≤60

60＜s≤70

70＜s≤85

85＜s≤100

100＜s≤125

125＜s≤150

Longitudinal

Transverse 6)

WStE500

610~780

600~770

590~760

580~750

570~740

500

480

470

460

450

440

430

420

410

16
