Product Introduction Technical Data

Product Introduction

EN10028 P275N steel plate/sheet, under EN standard, we can regard P275N steel plate/sheet for boilers and Pressure Vessels steels.EN10028 P275N steel plate/sheet is for boilers and Pressure Vessels steels, it is a normalized steel plate and sheet which is mainly used for building pressure vessels and boilers and pipes for hot liquid.

Under the standard EN10028_3,steel plate P275N shall be under Normalized delivery condition when processing.These steel grade P275NH and P275N mainly used in pressure vessels and boilers differ from other carbon_manganese structural steel plates owning to its high resistance to pressure at all temperatures when usage.

Technical Data

P275N Chemical Composition
Grade	The Element Max (%)
Grade	C	Si	Mn	P	S	Al(min)	N
P275N	0.18	0.40	0.5-1.40	0.030	0.025		0.02
	Cr	Cu	Mo	Nb	Ni	Ti	V
	0.30	0.30	0.08	0.005	0.50	0.03	0.05

Carbon Equivalent: Ceq = 【C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15】%

Grade	P275N Mechanical Property
Grade	Thickness	Yield	Tensile	Elongation	Impact Energy(KV J) min
P275N	mm	Min Mpa	Mpa	Min %	-20°	0°	+20°
	≤ 16	275	390-510	24	40	47	55
	16> to ≤35	275	390-510	24	40	47	55
	35> to ≤50	265	390-510	24	40	47	55
	50> to ≤70	255	390-510	24	40	47	55
	70> to ≤100	235	370-490	23	40	47	55
	100> to ≤150	235	350-470	23	40	47	55
