ASTM A516 GR.65 PRESSURE VESSEL PLATES

ASTM A516 standard specification for pressure vessel plates, carbon steel for moderate and lower- temperature service.

Grade : ASTM 516 GR.65 Boiler and Pressure Vessel Steel Plates
Width : 1500mm-3000mm
Thickness : 3 - 200 mm/ dimensions up to 4.000 mm
Length : 3000mm-11000mm.
Production : Hot-Rolled (HR)
Heat Treatment : Rolled/Normalised/N+T/QT

A516 Grade 65 Chemical Composition
Grade	The Element Max (%)
	C	Si	Mn	P	S
A516 grade 65
Thick <12.5mm	0.24	0.13-0.45	0.79-1.30	0.035	0.035
Thick12.5-50mm	0.26	0.13-0.45	0.79-1.30	0.035	0.035
Thick50-100mm	0.28	0.13-0.45	0.79-1.30	0.035	0.035
Thick100-200mm	0.29	0.13-0.45	0.79-1.30	0.035	0.035
Thick>200mm	0.29	0.13-0.45	0.79-1.30	0.035	0.035



Grade		A516 Grade 65 Mechanical Property
	Thickness	Yield	Tensile	Elongation
A516 grade 65	mm	Min Mpa	Mpa	Min  %
	6-40	240	450-585	23%
	40-100	240	450-585	19%

Delivery Status : Rolled/Normalised/N+T/QT

ASTM A516 plates 40mm and under in thickness is normally supplied in the as-rolled condition.
The plates may be ordered normalized or stress relieved, or both. ASTM A516 grade plates over 40mm in thickness shall be normalized.

Supplementary Technology:

HIC Test | NACE MR0175 | Z15 | Z25 | Z35 | S1 | S2 | S3 | S4.1
S5 | S6 | S7 | S8 | S9| S11 | S12 | S14 | S17
