ASTM A204 Grade A Pressure Vessel Steel plate

ASTM A204 Gr.A is a kind of Mo-alloy steel material used to fabric high temperature pressure vessels. A204 this property is based on it's Mo composition. ASTM A-204/A-204M A204 has three grades or levels-- Grade A/B/C. A204 steel grade specification covers molybdenum alloy, intended particularly of welded boilers and others pressure vessels steel plate in A204 Gr. A,A204 Gr .B and A204 Gr .C

A204 Grade A Chemical Composition
Grade	The Element Max (%)
	C	Si	Mn	P	S
A204 Grade A	0.18-0.25	0.13-0.45	0.90-0.98	0.035	0.035



Mechanical Property of A204 Grade A steel plate	A204 Grade A
Tensile strength, kis [MPa]	65-85 [450-585]
Yield strength, min, kis [MPa]	37 [255]
Elongation in 8 in. [200 mm], min, %	19
Elongation in 2 in. [50 mm], min, %	23

Supplementary Technology:   HIC Test | NACE MR0175 | Z15 | Z25 | Z35 | S1 | S2 | S3 | S4.1S5 | S6 | S7 | S8 | S9| S11 | S12 | S14 | S17
