A612 steel

This specification covers killed carbon- manganese-silicon steel plates intended for welded pressure vessels in service at moderate and lower temperatures. As a steel making practice, the steel shall be killed and shall conform to specified fine austenitic grain size requirements. Plates are normally supplied in the as-rolled condition.

A612 steel plate are commonly used throughout the oil industry including inshore and offshore, A612 steel plate can also be used for the petrochemical industry and the gas production industry.

Chemical Composition
The following composition properties are ASTM specifications for A612 using heat analysis.

A612
CARBON MAX	0.25%
MANGANESE	1.00-1.50%
PHOSPHORUS MAX	0.030%
SULFUR MAX	0.030%
SILICON	0.15-0.50%
COPPER MAX	0.35%
NICKEL MAX	0.25%
CHROMIUM MAX	0.25%
MOLYBDENUM MAX	0.08%
VANADIUM MAX	0.08%

The following material properties are ASTM specifications and will be confirmed on the Mill Test Report.

A612	YIELD POINT (KSI)	TENSILE STRENGTH (KSI)	MIN. 8” ELONGATION %
UNDER 0.5 IN. THICK	50	83-105	16
OVER 0.5 IN. TO 1 IN. THICK	50	81-101	16
