| OD | 10-700 mm | |||
| Thickness | Cold rolled:1~4.0mm | |||
| Hot rolled:4mm~20mm | ||||
| Length | 1-12M | |||
| Technology | Hot roll, cold roll, cold drawn, ect. | |||
| Material | 10#-45#, 16Mn, A53-A369, Q195-Q345, ST35-ST52 Grade A, Grade B, Grade C |
|||
| Standards | API 5L, ASTM A53-2007, ASTM A671-2006, ASTM A252-1998, ASTM A450-1996, ASME B36.10M-2004, ASTM A523-1996, BS 1387, BS EN10296, BS 6323, BS 6363, BS EN10219, GB/T 3091-2001, GB/T 13793-1992, GB/T9711 |
|||
| Certifications | MTC ISO9001 | |||
| Packing | Industry standard packaging or according to client's requirement | |||
| Payment | T/T,L/C,Western Union,Paypal,Apple Pay,Google Pay,D/A,D/P,MoneyGram | |||
| Delivery time | Usually 15 working days, your purchase volume determines our delivery time | |||
Chemical Properties %
| / | Grade | C, max |
Mn, max |
P, max |
S, max |
Cu*, max |
Ni*, max |
Cr*, max |
Mo*, max |
V*, max |
| Type S (Seamless) | A | 0.25 | 0.95 | 0.05 | 0.05 | 0.4 | 0.4 | 0.4 | 0.15 | 0.08 |
| B | 0.3 | 1.2 | 0.05 | 0.05 | 0.4 | 0.4 | 0.4 | 0.15 | 0.08 | |
| Type E (Electric-resistance Welded) | A | 0.25 | 0.95 | 0.05 | 0.05 | 0.4 | 0.4 | 0.4 | 0.15 | 0.08 |
| B | 0.3 | 1.2 | 0.05 | 0.05 | 0.4 | 0.4 | 0.4 | 0.15 | 0.08 | |
| Type F (Furnace-welded) | A | 0.3 | 1.2 | 0.05 | 0.05 | 0.4 | 0.4 | 0.4 | 0.15 | 0.08 |
*The total composition for these five elements shall not exceed 1.00%
Mechanical Properties
| Grade A | Grade B | |
| Tensile Strength, min., psi, (MPa) | 48,000 (330) | 60,000 (415) |
| Yield Strength, min., psi, (MPa) | 30,000 (205) | 35,000 (240) |
(Note: This is summarized information from ASME Specification A53. Please refer to the specific Standard or Specification or contact us for more details.)
Applications
1. Construction: the pipeline underneath, the groundwater, and the hot water transportation.
2. Mechanical processing, bearing sleeves, processing machinery parts, etc.
3. Electrical: Gas delivery, Hydroelectric power fluid pipeline
4. Anti-static tubes for wind power plants, etc.
