| Model Number | 1.9"-20" |
| Type | Coupling |
| Machine Type | Oil production |
| Certification | API |
| Material | Alloy steel |
| Processing Type | Turning |
| Surface treatment | Whole phosphating, or inside phosphating and outside coating |
| Usage | Internally threaded cylinder for joining two lengths of threaded casing pipe |
| Item Type | Casing coupling | Tubing coupling |
| Specification | 4-1/2", 5", 5-1/2", 6-5/8", 7", 7-5/8", 8-5/8", 9-5/8", 10-3/4",11-3/4", 13-3/8", 16", 18-5/8", 20" |
1.9", 2-3/8", 2-7/8", 3-1/2", 4", 4-1/2" |
| Steel grade | J55, K55, L80, N80, P110 | J55, L80, N80 |
| Thread type | STC, LTC, BTC | EUE, NUE |
Chemical Composition
| Grade | C≤ | Si≤ | Mn≤ | P≤ | S≤ | Cr≤ | Ni≤ | Cu≤ | Mo≤ | V≤ | Als≤ |
| API 5CT J55 | 0.34-0.39 |
0.20-0.35 |
1.25-1.50 |
0.020 |
0.015 |
0.15 |
0.20 |
0.20 |
/ |
/ |
0.020 |
| API 5CT K55 | 0.34-0.39 |
0.20-0.35 |
1.25-1.50 |
0.020 |
0.015 |
0.15 |
0.20 |
0.20 |
/ |
/ |
0.020 |
| API 5CT N80 | 0.34-0.38 |
0.20-0.35 |
1.45-1.70 |
0.020 |
0.015 |
0.15 |
/ |
/ |
/ |
0.11-0.16 |
0.020 |
| API 5CT L80 | 0.15-0.22 |
1.00 |
0.25-1.00 |
0.020 |
0.010 |
12.0-14.0 |
0.20 |
0.20 |
/ |
/ |
0.020 |
| API 5CT J P110 | 0.26-035 |
0.17-0.37 |
0.40-0.70 |
0.020 |
0.010 |
0.80-1.10 |
0.20 |
0.20 |
0.15-0.25 |
0.08 |
0.020 |
Mechanical Properties
|
Steel Grade |
Yield Strength (Mpa) |
Tensile Strength (Mpa) |
|
API 5CT J55 |
379-552 |
≥517 |
|
API 5CT K55 |
≥655 |
≥517 |
|
API 5CT N80 |
552-758 |
≥689 |
|
API 5CT L80 |
552-655 |
≥655 |
|
API 5CT P110 |
758-965 |
≥862 |
