Dimensional Range:
| Trade Name | API 5L X52 PSL2 Pipe |
| Weld Alternatives: | ERW, HF, DSAW/SAWL, SMLS, HSAW |
| OD Size Range: |
ERW: 0.375″ through 30″ SMLS: 0.840″ through 26″ |
| Wall Ranges: | ERW: 0.120″ through 1.000″ HF: 0.120″ through 1.000″ DSAW/SAWL: 0.250″ through 6.000″ SMLS: 0.250″ through 2.500″ |
| Lengths: | Single Random Double Random Custom (up to 300′) |
| Grade: | ASTM A53, ASTM A106, ASTM A179, ASTM A192, ST35.8, ST37, ST42, ST52, E235, E355, S235JRH, S275JR, S355JOH, P235TR1, 10#, 20#, 45#, Q235, Q345 |
| Schedule: | SCH5 SCH10 SCH20 SCH30 SCH40 SCH80 SCH120 SCH140 SCH160 SCHXS SCHXXS |
| Surface Finishes: | Bare, Oiled, Mill Varnish, Galv, FBE, FBE Dual, 3LPE, 3LPP, Coal Tar, Concrete Coating and Tape Wrap. |
| End Finishes: | Beveled, Square Cut, Threaded & Coupled. |
| Additional Services: | Internal Coating |
API X52 Chemical Composition
| X52 PSL1 | X52 PSL2 | |||||||
|
Grade |
C (Max.) |
Mn (Max.) |
P (Max.) |
S (Max.) |
C (Max.) |
Mn (Max.) |
P (Max.) |
S (Max.) |
|
X52 |
0.26 |
1.40 |
0.03 |
0.03 |
0.22 |
1.40 |
0.025 |
0.015 |
Physical Properties
| API 5L Grade | Yield Strength min. (ksi) |
Tensile Strength min. (ksi) |
Yield to Tensile Ratio (max.) |
Elongation min. %1 |
| X52 | 52 | 66 | 0.93 | 21 |
| API 5L-PSL 1 Mechanical Properties | |||
| Grade | Yield Strength Mpa | Tensile Strength Mpa | Elongation |
| B | 245 | 415 | c |
| X52 | 360 | 460 | c |
| API 5L-PSL 2 Mechanical Properties | ||||||
| Grade | Yield Strength Mpa | Tensile Strength Mpa | Raito | Elongation | ||
| min | max | min | max | max | min | |
| BN | 245 | 450 | 415 | 655 | 0.93 | f |
| BQ | ||||||
| X52N | 360 | 530 | 460 | 760 | 0.93 | f |
API 5L X52 Equivalent
| ASTM API 5L | Specification for line pipe | |
| Material Grade | PSL1 | L360 or x52 |
| Material Grade | PSL2 | L360N or X52N L360Q or X52Q L360M or X52M |
