API 5CT Grade J55 Casing Pipe Exporter

Our oilfield tubing and J55 Tubing Material can be generally relevant to oil, development, shipbuilding, refining, aeronautics, electric power, sustenance, paper, compound industry, restorative hardware, boilers, heat exchangers, metallurgy, etc.

This oilfield tubing can be delegated NUE type and EUE type. You can discover here Seamless 5ct j55 Petroleum Casing Pipe Dimensions and Casing Wall Thickness. Determinations incorporate 1.9in(48.3mm), 2 3/8in(60.3mm), 2 7/8in(73.03mm), 3 1/2in(88.9mm), 4in(101.6mm), 4 1/2in(114.3mm) and so forth. The profundity of our item to plummet the well is fundamentally indistinguishable to that of oil packaging channel. Both mechanical property and fixing execution of this tubing are additionally required to relate with the oil packaging funnel. Oil Tubing fundamental steel grade incorporates J55, N80, C90, P110 and some others. for more subtleties check beneath Casing And Tubing Tables, Casing Grade Table, and Casing Data Tables.

API 5CT J55 Group	API 5CT J55 Grade	API 5CT J55 Type	API 5CT J55 C		API 5CT J55 Mn		API 5CT J55 Mo		API 5CT J55 Cr		API 5CT J55 Ni max.	API 5CT J55 Cu max.	API 5CT J55 P max.	API 5CT J55 S max.	API 5CT J55 Si max.
			min.	max.	min.	max.	min.	max.	min.	max.
1	2	3	4	5	6	7	8	9	10	11	12	13	14	15	16
1	H40	-	-	-	-	-	-	-	-	-	-	-	0.03	0.03	-
	J55	-	-	-	-	-	-	-	-	-	-	-	0.03	0.03	-
	K55	-	-	-	-	-	-	-	-	-	-	-	0.03	0.03	-
	N80	1	-	-	-	-	-	-	-	-	-	-	0.03	0.03	-
	N80	Q	-	-	-	-	-	-	-	-	-	-	0.03	0.03	-
	R95	-	-	0.45 c	-	1.9	-	-	-	-	-	-	0.03	0.03	0.45
2	M65	-	-	-	-	-	-	-	-	-	-	-	0.03	0.03	-
	L80	1	-	0.43 a	-	1.9	-	-	-	-	0.25	0.35	0.03	0.03	0.45
	L80	9Cr	-	0.15	0.3	0.6	0.9	1.1	8	10	0.5	0.25	0.02	0.01	1
	L80	13Cr	0.15	0.22	0.25	1	-	-	12	14	0.5	0.25	0.02	0.01	1
	C90	1	-	0.35	-	1.2	0.25 b	0.85	-	1.5	0.99	-	0.02	0.01	-
	T95	1	-	0.35	-	1.2	0.25 d	0.85	0.4	1.5	0.99	-	0.02	0.01	-
	C110	-	-	0.35	-	1.2	0.25	1	0.4	1.5	0.99	-	0.02	0.005	-
3	P110	e	-	-	-	-	-	-	-	-	-	-	0.030 e	0.030 e	-
4	Q125	1	-	0.35		1.35	-	0.85	-	1.5	0.99	-	0.02	0.01	-
a The carbon content for L80 may be increased up to 0.50 % maximum if the product is oil-quenched.  b The molybdenum content for Grade C90 Type 1 has no minimum tolerance if the wall thickness is less than 17.78 mm.  c The carbon content for R95 may be increased up to 0.55 % maximum if the product is oil-quenched.  d The molybdenum content for T95 Type 1 may be decreased to 0.15 % minimum if the wall thickness is less than 17.78 mm.  e For EW Grade P110, the phosphorus content shall be 0.020 % maximum and the sulfur content 0.010 % maximum.  NL = no limit. Elements shown shall be reported in product analysis.

API 5CT J55 Casing Tubing Features：
The surface of thread of coupling and API 5CT J55 Casing Tubing should be smooth without any tear, burr or other defects that may have a negative impact on the strength and close connection.
API 5CT J55 Casing Tubing is offered with a free length range from 8m to 13m on basis of the SY/T6194-96 norm. However, it is also available no less than 6m length and its quantity should be no more than 20%.
Deformations which mentioned above are not allowed to appear on the outer surface of API 5CT J55 Casing Tubing coupling.
Any deformation such as crease, separation, hairline, crack or scab is not acceptable on both inner and outer surfaces of the product. All these defects should be completely removed, and the removed depth must not exceed 12.5% of nominal wall thickness.
