Stainless steel 430,430F

Stainless steel 430 is a non-hardenable steel containing straight chromium, and belongs to the ferritic group of steels. This steel is known for its good corrosion resistance and formability, coupled with practical mechanical properties. It can be used in certain chemical applications due to its resistance to nitric acid. 430F stainless steel is usually provided in bar form to be used in automatic screw machines. factory Standard AISI ASTM hot/cold roll stainless steel plate.

Product Details

type	SS steel plate	brand	Gnee
material	304 304l  201 430 316 904	surface	ba 2B
tech.	cold  rolled steel	Certification	tisco baosteel jisco
thich,	60mm- 2000mm	Standard	AISI, ASTM, DIN, EN, GB, JIS

Chemical Composition

GradeN		C	Mn	Si	P	S	Cr	Mo	Ni	N
430	min. max.	- 0.12	- 1	- 1	- 0.04	- 0.030	16 18	-	- 0.50	-
430F	min. max.	- 0.12	- 1.25	- 1	- 0.06	0.15 -	16 18	-	-	-

Mechanical Properties

Grade	Tensile Strength (MPa) min	Yield Strength 0.2% Proof (MPa) min	Elongation (% in 50mm) min	Hardness
				Rockwell B (HR B) max	Brinell (HB) max
430	483	310	22	85	183
430F	552 typical	379 typical	25 typical	-	262

Physical Properties

Grade	Density (kg/m3)	Elastic Modulus (GPa)	Mean Coefficient of Thermal Expansion (μm/m/°C)			Thermal Conductivity (W/m.K)		Specific Heat 0-100°C (J/kg.K)	Electrical Resistivity (nΩ.m)
			0-100°C	0-315°C	0-538°C	at 100°C	at 500°C
430	7750	200	10.4	11.0	11.4	26.1	26.3	460	600
430F	7750	200	10.4	11.0	11.4	26.1	26.3	460	600

Grade Specification Comparison

Grade	UNS No	Old British		Euronorm		Swedish SS	Japanese JIS
		BS	En	No	Name
430	S43000	430S17	60	1.4016	X8Cr17	2320	SUS 430
430F	S43020	-	-	1.4104	X12CrMoS17	2383	SUS 430F

Possible Alternative Grades

Grade	Reasons for choosing 430
430F	Higher machinability than 430 is needed in bar product, and reduced corrosion resistance is acceptable
434	Better pitting resistance is required
304	Slightly higher corrosion resistance is needed, together with greatly improved ability to be welded and cold formed
316	Much better corrosion resistance is needed, coupled with greatly improved ability to be welded and cold formed
3CR12	Lower corrosion resistance is acceptable in a cost-critical application
